‘Molecular glue’ makes perovskite solar cells tougher

A “molecular glue” dramatically increases the stability and reliability of perovskite solar cells over time, researchers report in a new study.

The treatment, which keeps a key interface inside the cells from degrading, also improves the efficiency with which they convert sunlight into electricity.

“There have been great strides in increasing the power-conversion efficiency of perovskite solar cells,” says senior author Nitin Padture, a professor of engineering at Brown University.

“But the final hurdle to be cleared before the technology can be widely available is reliability—making cells that maintain their performance over time. That’s one of the things my research group has been working on, and we’re happy to report some important progress.”

Perovskite layers pose a problem

Perovskites are a class of materials with a particular crystalline atomic structure. A little over a decade ago, researchers showed that perovskites are very good at absorbing light, which set off a flood of new research into perovskite solar cells.

The efficiency of those cells has increased quickly and now rivals that of traditional silicon cells. The difference is that it’s possible to make perovskite light absorbers at near room temperature, whereas silicon needs to be grown from a melt at a temperature approaching 2,700 degrees Fahrenheit. Perovskite films are also about 400 times thinner than silicon wafers. The relative ease of the manufacturing processes and the use of less material means perovskite cells can potentially be made at a fraction of the cost of silicon cells.

While the efficiency improvements in perovskites have been remarkable, making the cells more stable and reliable has remained challenging, Padture says.

“A chain is only as strong as its weakest link, and we identified this interface as the weakest part of the whole stack, where failure is most likely.”

Part of the problem has to do with the layering required to make a functioning cell. Each cell contains five or more distinct layers, each performing a different function in the electricity-generation process. Since these layers are made from different materials, they respond differently to external forces.

Also, temperature changes that occur during the manufacturing process and during service can cause some layers to expand or contract more than others. That creates mechanical stresses at the layer interfaces that can cause the layers to decouple. If the interfaces are compromised, the performance of the cell plummets.

The weakest of those interfaces is the one between the perovskite film used to absorb light and the electron transport layer, which keeps current flowing through the cell.

“A chain is only as strong as its weakest link, and we identified this interface as the weakest part of the whole stack, where failure is most likely,” says Padture, who directs the Institute for Molecular and Nanoscale Innovation at Brown. “If we can strengthen that, then we can start making real improvements in reliability.”

To do that, Padture drew on his experience as a material scientist, developing advanced ceramic coatings used in aircraft engines and other high-performance applications. He and colleagues began experimenting with compounds known as self-assembled monolayers or SAMs.

“This is a large class of compounds,” Padture says. “When you deposit these on a surface, the molecules assemble themselves in a single layer and stand up like short hairs. By using the right formulation, you can form strong bonds between these compounds and all kinds of different surfaces.”

Shocking improvement

Padture and his team found that a formulation of SAM with silicon atom on one side, and iodine atom on the other, could form strong bonds with both the election transport layer (which is usually made of tin oxide) and the perovskite light-absorbing layer. The team hoped that the bonds formed by these molecules might fortify the layer interface. And they were right.

“When we introduced the SAMs to the interface, we found that it increases the fracture toughness of the interface by about 50%, meaning that any cracks that form at the interface tend not to propagate very far,” Padture says. “So in effect, the SAMs become a kind of molecular glue that holds the two layers together.”

“That we could improve reliability without losing efficiency—and even improving efficiency—was a nice surprise.”

Testing of solar cell function showed that the SAMs dramatically increased the functional life of the perovskite cells. Non-SAM cells prepared for the study retained 80% of their peak efficiency for around 700 hours of lab testing. Meanwhile, the SAM cells were still going strong after 1,300 hours of testing. Based on those experiments, the researchers project the 80%-efficiency-life of the SAM cells to be about 4,000 hours.

“One of the other things we did, which people don’t normally do, is we broke open the cells after testing,” says Zhenghong Dai, a doctoral student and first author of the research. “In the control cells without the SAMs, we saw all kinds of damage such as voids and cracks. But with the SAMs, the toughened interfaces looked really good. It was a dramatic improvement that really kind of shocked us.”

Tougher and more efficient

Importantly, Padture says, the improvement in toughness did not come at the cost of power-conversion efficiency. In fact, the SAMs actually improved the cell’s efficiency by a small amount. That occurred because the SAMs eliminated tiny molecular defects that form when the two layers bond in the absence of SAMs.

“The first rule in improving the mechanical integrity of functional devices is ‘do no harm,'” Padture says. “So that we could improve reliability without losing efficiency—and even improving efficiency—was a nice surprise.”

The SAMs themselves are made from readily available compounds and are easily applied with a dip-coating process at room temperature. So the addition of SAMs would potentially add little to the production cost, Padture says.

The researchers plan to build on this success. Now that they’ve fortified the weakest link in the perovskite solar cell stack, they’d like to move onto the next weakest, then the next, and so on until they’ve fortified the entire stack. That work will involve strengthening not only the interfaces, but also the material layers themselves.

“This is the kind of research that’s required in order to make cells that are inexpensive, efficient, and perform well for decades,” Padture says.

The research appears in Science.

The Office of Naval Research and the National Science Foundation funded the work.

Source: Brown University
